1.Dimensions



Width: 305mm
Depth: 305mm
Height: 110mm
Weight: 15KG


2.Electrical data



Nominal input voltage: 220V(100V-240V)
Frequency: 50/60 Hz
Input Power: 50VA
Rated output voltage(to gun):
12~18VPP

Rated output current(to gun): 1.2A
Protection type: IP54
Temperature rang: +10℃ to +40℃(+50℉ to +104℉)
Solenoid Valve Volatge: 24VDC
Gun output voltage: 0-100KVDC
Gun output current: 0-100μA
